CFLO250 Heat Recovery Ventilation Condensation 3,4,5,6,8,10 Rooms Complete Kit

CFLO250 Heat Recovery Ventilation Condensation 3,4,5,6,8,10 Rooms Complete Kit
Regular price £449.99

Please select what you require above

In this kit you will receive the following:

CFLO250 unit x 1

Reducer 6" to 5" x 4

External grilles x 2

Tee pieces to match selection

Insulated ducting x 5 (50m Total 5")

Internal grilles to match the selection

3 to 6 room kit - 6 internal Grille

4 to 8 room kit - 8 internal Grilles

5 to 10 room kit - 10 internal grilles

Alu Tape x 1



Wall In line Void/Loft Mounted Heat Recovery Unit Only

Unit label airflow is incorrect unit does 550 m3/hr on full speed

Boost switch comes wired to unit (plug straight in)

** There should never be two lives going to the unit at the same time **

Comes with easy unscrew lid and condensation drain
Please note all airflows are at free air (No pressure)

Features

W415 x H255 x L450
70mm added to width for terminal box
60mm spigot length needs to be added to length

Designed to run continuously and provide adequate ventilation for a bathroom, en suite, shower room, wet room etc.

Will provide up to 75% heat recovery

(As air is extracted the unit will recover up to 75% of the heat and add it to clean fresh air, and pump it back into your house.)

6" 150mm Spigots on unit

Comes with 7 speeds controller is wired to 2 for trickle and boost
Eliminate mould and control condensation
Trickle/Boost Option included
Loft/void space mounting.
Condensation Drain fitted to bottom of Unit

Extract Rates needed when using continuous Ventilation (boost)

Kitchen - 13 l/s
Utility - 8 l/s
Bathroom - 8 l/s
Sanitary Accommodation - 6l/s

  • guaranteeQuality checked
  • Free ShippingStandard Delivery
  •


Please select what you require above

In this kit you will receive the following:

CFLO250 unit x 1

Reducer 6" to 5" x 4

External grilles x 2

Tee pieces to match selection

Insulated ducting x 5 (50m Total 5")

Internal grilles to match the selection

3 to 6 room kit - 6 internal Grille

4 to 8 room kit - 8 internal Grilles

5 to 10 room kit - 10 internal grilles

Alu Tape x 1



Wall In line Void/Loft Mounted Heat Recovery Unit Only

Unit label airflow is incorrect unit does 550 m3/hr on full speed

Boost switch comes wired to unit (plug straight in)

** There should never be two lives going to the unit at the same time **

Comes with easy unscrew lid and condensation drain
Please note all airflows are at free air (No pressure)

Features

W415 x H255 x L450
70mm added to width for terminal box
60mm spigot length needs to be added to length

Designed to run continuously and provide adequate ventilation for a bathroom, en suite, shower room, wet room etc.

Will provide up to 75% heat recovery

(As air is extracted the unit will recover up to 75% of the heat and add it to clean fresh air, and pump it back into your house.)

6" 150mm Spigots on unit

Comes with 7 speeds controller is wired to 2 for trickle and boost
Eliminate mould and control condensation
Trickle/Boost Option included
Loft/void space mounting.
Condensation Drain fitted to bottom of Unit

Extract Rates needed when using continuous Ventilation (boost)

Kitchen - 13 l/s
Utility - 8 l/s
Bathroom - 8 l/s
Sanitary Accommodation - 6l/s
