CFLO100 Heat Recovery Unit/Fan Whole House Ventilation System (HRU100)

Void/Loft Mounted Heat Recovery Unit

Boost switch comes wired to unit (plug straight in)

** There should never be two lives going to the unit at the same time **

Comes with easy unscrew lid and condensation drain

Air Performance and watts


Features

Designed to run continuously and provide adequate ventilation for a single bathroom, en suite, shower room, wet room.

Will provide up to 75% heat recovery

(As air is extracted the unit will recover up to 75% of the heat and add it to clean fresh air, and pump it back into your house.)

Eliminate mould and control condensation

Trickle/Boost Option

Loft/void space mounting.

Condensation Drain fitted to bottom of Unit

If kit is needed please see our SHOP examples below

HRU100 (CFLO100) unit does 27.7 l/s @ Free Air
Remember the more ducting, Bends & Grilles you use the less performance from the fan

2 room kit Example
Extract: bathroom (8 l/s)
Supply: Hall way (6 l/s)
3 Room Kit Example
Extract: En Suit + Bathroom (16 l/s)
Supply: Hall Way (6 l/s)
4 Room Kit Example
Extract: Toilet + En Suit + Bathroom (22 l/s)
Supply: Hall Way (6 l/s)

Extract Rates needed when using continuous Ventilation (boost)

Kitchen - 13 l/s
Utility - 8 l/s
Bathroom - 8 l/s
Sanitary Accommodation - 6l/s
