STY100 Humidity Timer Std 12v Extractor Fan
STY100 Humidity Timer Std 12v Extractor Fan
2 reviews
Regular price
£42.99
Regular price
Sale price
£42.99
Unit price
/
per
Taxes included.
Shipping calculated at checkout.
In stock
Couldn't load pickup availability
Description
Description
Swiftair STY100 12v - 1 Year Warranty
PLEASE SELECT WHAT YOU NEED ABOVE FROM THE DROP DOWN MENU
Comes with Backdraught Shutter + Transformer
Please see how to wire below on the transformer you will have II and I every thing going to the fan must be from the transformer
Standard Model: Live and neutral to transformer and 12v feed to fan
Timer model: Permanent Live and neutral to transformer >>>> II 12v - to Live (L), then II 12v to a Switch (not provided) then to switched live (S/L) , I to Neutral (N)
Humidity with timer: Permanent Live and neutral to transformer >>>> II 12v - to Live (L), then II 12v to a Switch (not provided) then to switched live (S/L) , I to Neutral (N)
Humidity Only: Permanent Live and neutral to transformer >>>> II 12v - to Live (L), I to Neutral (N)
Specification:
Air Extraction m3/hr : 70m3/hr
Air Extraction L/s : 19 L/s
Noise : 30dB(A) (Low Noise)
Watts : 15W
STY100 12v White Extractor Fan Range Overview
100mm (4") Bathroom/ Toilet Fans incorporates the latest technology and design and offers the most comprehensive range with the widest choice of options and variations.
Attractively styled in high gloss ABS thermoplastics for modern appearance and ease of cleaning, designed for easy installation and can be wall mounted.
There are several options available; Standard model for remote switching,and Timer models which incorporate an electronic time delay switch. Humidistat Control models are also available which are designed to switch on the fan as the humidity rises in the bathroom and off as it drops.
Construction
These fans are moulded in impact resistant high gloss ABS thermoplastics for strength, durability and finish.
Electrical
Transformer 220-240V ~ A.C. 50Hz Single phase.
Fans - 12v (15 watt)
These fans are double insulated and do not require an earth. All wiring must comply with current IEE regulations. A double pole isolating switch, having a contact separation of at least 3mm in all poles, must be used with a 3 amp fuse fitted.
Motor
Single phase induction motor with pre-oiled bearings fitted for a long maintenance free life and protected by a thermal fuse.
Installation
STY100 Series designed to be mounted on walls through 100mm (4") diameter flexible or rigid pipes.
Performance
The extract rate of all models is 70m³hr, 19 litres per second.
Additional Data
Maximum pressure: 15 p.a. Fan speed: 2400 r.p.m.
PLEASE SELECT WHAT YOU NEED ABOVE FROM THE DROP DOWN MENU
Comes with Backdraught Shutter + Transformer
Please see how to wire below on the transformer you will have II and I every thing going to the fan must be from the transformer
Standard Model: Live and neutral to transformer and 12v feed to fan
Timer model: Permanent Live and neutral to transformer >>>> II 12v - to Live (L), then II 12v to a Switch (not provided) then to switched live (S/L) , I to Neutral (N)
Humidity with timer: Permanent Live and neutral to transformer >>>> II 12v - to Live (L), then II 12v to a Switch (not provided) then to switched live (S/L) , I to Neutral (N)
Humidity Only: Permanent Live and neutral to transformer >>>> II 12v - to Live (L), I to Neutral (N)
Specification:
Air Extraction m3/hr : 70m3/hr
Air Extraction L/s : 19 L/s
Noise : 30dB(A) (Low Noise)
Watts : 15W
STY100 12v White Extractor Fan Range Overview
100mm (4") Bathroom/ Toilet Fans incorporates the latest technology and design and offers the most comprehensive range with the widest choice of options and variations.
Attractively styled in high gloss ABS thermoplastics for modern appearance and ease of cleaning, designed for easy installation and can be wall mounted.
There are several options available; Standard model for remote switching,and Timer models which incorporate an electronic time delay switch. Humidistat Control models are also available which are designed to switch on the fan as the humidity rises in the bathroom and off as it drops.
Construction
These fans are moulded in impact resistant high gloss ABS thermoplastics for strength, durability and finish.
Electrical
Transformer 220-240V ~ A.C. 50Hz Single phase.
Fans - 12v (15 watt)
These fans are double insulated and do not require an earth. All wiring must comply with current IEE regulations. A double pole isolating switch, having a contact separation of at least 3mm in all poles, must be used with a 3 amp fuse fitted.
Motor
Single phase induction motor with pre-oiled bearings fitted for a long maintenance free life and protected by a thermal fuse.
Installation
STY100 Series designed to be mounted on walls through 100mm (4") diameter flexible or rigid pipes.
Performance
The extract rate of all models is 70m³hr, 19 litres per second.
Additional Data
Maximum pressure: 15 p.a. Fan speed: 2400 r.p.m.
Sound volume: 30.0 dB(A) Maximum operating temperature 40° C.
