XFLO Inline Duct Extractor Fan Standard or Timer
XFLO Inline Duct Extractor Fan Standard or Timer
26 reviews
Regular price
£39.00
Regular price
Sale price
£39.00
Unit price
/
per
Taxes included.
Shipping calculated at checkout.
In stock
Couldn't load pickup availability
Description
Description
Timer Models Available please select above run on timer (Adjustable 1-15min)
Standard Model comes with plug however if not needed please remove.
XFLO fans are applied for supply and exhaust ventilation systems of commercial, office and other premises. Compatible with Ø 100, 125, 150, & 200mm round air ducts.
Due to the corrosion-resistant durable plastic casing, these models are the perfect solution for the installation in exhaust ventilation systems in humid premises such as bathrooms, kitchens etc.
A dynamic balanced impeller
Overheating protection
Motor protection rating IP X4
1 Year Warranty
Installation to the wall or ceiling can be performed by means of mounting bracket (included). The fan can be mounted at any angle. Electric connection and installation shall be performed in compliance with the manual and the wiring diagram on the terminal box.
Standard Model comes with plug however if not needed please remove.
XFLO fans are applied for supply and exhaust ventilation systems of commercial, office and other premises. Compatible with Ø 100, 125, 150, & 200mm round air ducts.
Due to the corrosion-resistant durable plastic casing, these models are the perfect solution for the installation in exhaust ventilation systems in humid premises such as bathrooms, kitchens etc.
A dynamic balanced impeller
Overheating protection
Motor protection rating IP X4
1 Year Warranty
Installation to the wall or ceiling can be performed by means of mounting bracket (included). The fan can be mounted at any angle. Electric connection and installation shall be performed in compliance with the manual and the wiring diagram on the terminal box.
Air Flow (Free Air)
100mm (4") - 220m3/hr (61l/s) (Timer model 250m3/hr)
125mm (5") - 330m3/hr (92l/s)
150mm (6") - 530m3/hr (147l/s)
200mm (8") - 820m3/hr (228l/s)
250mm (10") - 1405m3/hr (390l/s)
315mm (12") - 2206m3/hr (612l/s)
Sizes/Types
100mm (4") - XFLO100
125mm (5") - XFLO125
150mm (6") - XFLO150
200mm (8") - XFLO200
250mm (10") - XFLO250
315mm (12") - XFLO315
Timer - T
Standard - S
Wattage
Timer Model - 100mm (4") - 18w EC Motor
100mm (4") - 24/30w
125mm (5") - 26/33w
150mm (6") - 40/50w
200mm (8") - 100/130w
250mm (10") - 165/225w
315mm (12") - 275/380w
Sound Level dBA
100mm (4") - 35
125mm (5") - 37
150mm (6") - 44
200mm (8") - 48
250mm (10") - 66
315mm (12") - 69
