XFLO Inline Duct Extractor Fan Standard or Timer

XFLO Inline Duct Extractor Bathroom Fan 4" 5" 6" 8" upto 820m3/h
Regular price £39.00
Timer Models Available please select above run on timer (Adjustable 1-15min)

Standard Model comes with plug however if not needed please remove.

XFLO fans are applied for supply and exhaust ventilation systems of commercial, office and other premises. Compatible with Ø 100, 125, 150, & 200mm round air ducts.

Due to the corrosion-resistant durable plastic casing, these models are the perfect solution for the installation in exhaust ventilation systems in humid premises such as bathrooms, kitchens etc.

A dynamic balanced impeller

Overheating protection

Motor protection rating IP X4

1 Year Warranty

Installation to the wall or ceiling can be performed by means of mounting bracket (included). The fan can be mounted at any angle. Electric connection and installation shall be performed in compliance with the manual and the wiring diagram on the terminal box.

Air Flow (Free Air)
100mm (4") - 220m3/hr (61l/s)
125mm (5") - 330m3/hr (92l/s)
150mm (6") - 530m3/hr (147l/s)
200mm (8") - 820m3/hr (228l/s)
250mm (10") - 1405m3/hr (390l/s)
315mm (12") - 2206m3/hr (612l/s)


Sizes/Types

100mm (4") - XFLO100
125mm (5") - XFLO125
150mm (6") - XFLO150
200mm (8") - XFLO200
250mm (10") - XFLO250
315mm (12") - XFLO315


Timer - T
Standard - S


Wattage
100mm (4") - 24/30w
125mm (5") - 26/33w
150mm (6") - 40/50w
200mm (8") - 100/130w
250mm (10") - 165/225w
315mm (12") - 275/380w


Sound Level dBA
100mm (4") - 35
125mm (5") - 37
150mm (6") - 44
200mm (8") - 48
250mm (10") - 66
315mm (12") - 69

In stock Sold out Sold out (Backorder available)

Timer Models Available please select above run on timer (Adjustable 1-15min)

Standard Model comes with plug however if not needed please remove.

XFLO fans are applied for supply and exhaust ventilation systems of commercial, office and other premises. Compatible with Ø 100, 125, 150, & 200mm round air ducts.

Due to the corrosion-resistant durable plastic casing, these models are the perfect solution for the installation in exhaust ventilation systems in humid premises such as bathrooms, kitchens etc.

A dynamic balanced impeller

Overheating protection

Motor protection rating IP X4

1 Year Warranty

Installation to the wall or ceiling can be performed by means of mounting bracket (included). The fan can be mounted at any angle. Electric connection and installation shall be performed in compliance with the manual and the wiring diagram on the terminal box.

Air Flow (Free Air)
100mm (4") - 220m3/hr (61l/s)
125mm (5") - 330m3/hr (92l/s)
150mm (6") - 530m3/hr (147l/s)
200mm (8") - 820m3/hr (228l/s)
250mm (10") - 1405m3/hr (390l/s)
315mm (12") - 2206m3/hr (612l/s)


Sizes/Types

100mm (4") - XFLO100
125mm (5") - XFLO125
150mm (6") - XFLO150
200mm (8") - XFLO200
250mm (10") - XFLO250
315mm (12") - XFLO315


Timer - T
Standard - S


Wattage
100mm (4") - 24/30w
125mm (5") - 26/33w
150mm (6") - 40/50w
200mm (8") - 100/130w
250mm (10") - 165/225w
315mm (12") - 275/380w


Sound Level dBA
100mm (4") - 35
125mm (5") - 37
150mm (6") - 44
200mm (8") - 48
250mm (10") - 66
315mm (12") - 69
